Craftsman Glazing is extremely proud to maintain our 10 year certified partnership with SCHÜCO to design, manufacture and install spectacular glazing solutions. We are thrilled to be partnered with a company that sets the highest industry standard for continuity, quality, efficiency, environmentally conscious options, extensive North American Test Data and sophisticated 3D computer design and fabrication aides.
The products offer a high degree of design flexibility and attractive design options with any available architectural aluminum finishes. When you choose SCHÜCO products by Craftsman your products are warranted by the SCHÜCO limited warranty. Installation services available by Craftsman technicians whom have undergone SCHÜCO installation training. Products are finished + fabricated + machined 100% in house at our Vancouver facilities using state of the art machinery which supports our local manufacturing economy.

SCHÜCO façade FWS 50/60

The Schüco Façade FWS 50 / FWS 60 offers a high degree of flexibility and attractive design options for façades and skylight areas – including optimised fabrication and installation processes. A further benefit is that the façade guarantees the best thermal insulation values as a passive house-certified SI system. With the expansion of the façade range to include the Schüco FWS 50.SI system, Schüco is once again meeting its ecological requirement for sustainable products. The system has been awarded the Silver "Cradle-to-Cradle Certified™" sustainability label.
For more technical details please view the PDF.
SCHÜCO AWS Windows

The Schüco AWS aluminium window system combines the excellent thermal insulation properties of PVC-U and timber windows with the unique advantages of aluminium:
durability and stability, narrow face widths and a variety of designs - in large, transparent formats. With a basic depth of just 75 mm, this window system offers excellent versatility and can easily be combined with the Schüco range of doors ADS.
In combination with the concealed fittings Schüco AvanTec and Schüco TipTronic, Schüco AWS 75.SI meets the very highest standards in terms of both design and ease of use.
For more technical details please view the PDF.
SCHÜCO ADS75.HD.HI Aluminum Door System
The large doors from the Schüco Door ADS HD (Heavy Duty) system can be used as a striking feature. They endow every building with a specific character. Schüco door systems offer large opening widths/heights, durability and excellent thermal efficiency.
Size Limitations
1450 x 3000 mm
Up to 200 kg
For more technical details please view the PDF.

SCHÜCO AWS 75.SI Vent Window

The Schüco AWS 75.SI Vent Window features outstanding thermal insulation without compromising of comfort, design and functionality. Motorised solutions possible with Schüco TipTronic.
Size Limitations
1750 x 2150 mm
Up to 180 kg
Thermal Value
Uw = 1.59 W/m2K
Based on 1200 x 1500 mm window, 25 mm double glazed sealed unit with TGI Wave spacer and Solarban 60 coating (Ug = 1.36 W/m2K).
For more technical details please view the PDF.
SCHÜCO AWS 75.SI Terrace Door

The Schüco AWS 75.SI Terrace Door is a cost effective door solution to access terraces with outstanding thermal insulation without compromising of comfort, design and functionality.
Size Limitations
1750 x 2150 mm
Up to 180 kg
Thermal Value
Uw = 1.59 W/m2K
Based on 1200 x 1500 mm window, 25 mm double glazed sealed unit with TGI Wave spacer and Solarban 60 coating (Ug = 1.36 W/m2K).
For more technical details please view the PDF.
SCHÜCO AWS 114 Vent Window

The Schüco AWS 114 is a highly thermally insulated parallel-opening or projected top-hung window. The appearance of the innovative system with large vent formats can be integrated seamlessly into different façade geometries – even for vent weights of up to 250 kg. The comprehensive glazing range enables custom-built solutions. Motorised solutions possible with Schüco TipTronic.
Maximum permitted vent dimensions:
1300 x 3600 mm (51" x 141")
or 2200 x 2500 mm (86" x 98") as parallel-opening window,
1500 x 3600 mm (59" x 141") or 2700 x 2500 mm (106" x 98") as projected top-hung window.
Up to 250kg / 551lbs
For more technical details please view the PDF.
SCHÜCO ASE 80 Sliding Door System
The Schüco ASE 80 (Aluminium Sliding Element) sliding system range. The profile system with its optimised insulation zones offers significantly improved thermal insulation properties in all basic depths, even up to passive house level. Single, double and triple track options are available. Sliding or lift and slide hardware and slimline profiles complement the pioneering thermal insulation, fulfilling countless architectural design options.
For more technical details please view the PDF.

SCHÜCO ASS 70.HI Sliding System

Highly thermally insulated sliding and lift-and-slide system with excellent watertightness and sound reduction. Single, double and triple-track outer frames permit large opening widths with outstanding user comfort – perfect for use as a high-quality system solution in commercial projects and luxury residential properties.
For more technical details please view the PDF.
SCHÜCO ASS 80 FD.HI

The unrivalled Schüco Folding Sliding System ASS 80 FD.HI.
Its narrow face widths and wide range of designs with units that can be folded to the right, left, inwards or outwards make it an impressive solution for commercial projects as well as luxury homes. The Schüco ASS 80 FD.HI system is also characterised by its ease of operation.
Size Limitations
1200 x 3000 mm (47" x 118") per leaf
Up to 100 kg (220 lbs)
Thermal Value
Uw = 1,675 W/m2K (vision area 76 %)
Based on 5000 x 2500 mm large 5 panel door, 25 mm double glazed sealed unit with TGI Wave spacer and Solarban 60 coating (Ug = 1.36 W/m2K).
For more technical details please view the PDF.
